Custom Size Touch Screen

The 8 inch custom size touch screen is a 10-point capacitive touch screen which can be equipped with 800*600, 1024*768 lcd display. The touch is very smooth and brings you very good experience.
The 8 inch custom size touch screen has good anti-interference performance, support customization of various structures, surface treatment Anti-Glare Anti-Reflection Anti-Fingerprint and other special effects.

Send Inquiry

Download

Description

Technical Parameters

Product Description

-The 8 inch custom size touch screen uses industrial touch chip CYPRESS IC, can work with a variety of complex application environment. Such as work well with 3-10mm thickness cover glass, gloves,water, seawater, 5% saline and PC material onside.

-The 8 inch custom size touch screen is mainly used in financial portable terminal, medical electronics, indoor handheld terminal, intelligent security and other fields.

-Since the touch screen is made by experienced workers with exquisite craftsmanship, it has good treatment that it has smooth and glossy surface with no burrs, which touches comfortable.

Product Specification

TPM	Model Number	HX0801809
	Brand	Grahowlet
	Size	8.0 inch
	Operating Temperature	-20℃ ~ 70℃
	Storage Temperature	-30℃ ~ 80℃
	Outline Dimension	191.00(W)x149.00(H)x10.45(D) mm
	Viewing Area	163.00(W)x122.50(H) mm
	Active Area	162.00(W)x121.50(H) mm
	Support Systems	Windows/Android/Linux etc.
	Warranty	12 months
CTP	Interface Type	IIC/USB
	Material/Structure	Glass+Glass
	Controller IC	Cypress
	Touch Points	10 points
	Transparency	≥85%
	Surface Hardness	≥6H
	Power Supply Voltage	2.8V ~ 3.3V
TFT	Resolution	800x600
	Interface Type	RGB
	Luminance	900 cd/㎡
	Viewing Angle	70/70/50/70
