Circular Touch Screen

The custom circular touch screen uses industrial touch chip CYPRESS IC, can work with a variety of complex application environment. Such as work well with 5-10mm thickness cover glass, gloves, water, seawater, 5% saline and PC material onside.
The custom circular touch screen is mainly used in financial portable terminal, medical electronics, indoor handheld terminal, intelligent security and other fields.

Send Inquiry

Description

Technical Parameters

-The custom circular touch screen is a 10 point capacitive touch screen that can match the HD resolution LCD display. The touch is very smooth and brings you perfect experience.

-The custom circular touch screen has good anti-interference performance, support customization of various structures, surface treatment Anti-Glare Anti-Reflection Anti-Fingerprint and other special effects.

Model Number	HX0401601
Brand	Grahowlet
Size	4.0 inch
Interface Type	USB/IIC
Structure	G+F+F
Controller IC	Goodix/CYPRESS
Touch Points	10 points
Transparency	≥85%
Surface Hardness	≥6H
Operating Environment	-20℃ ~ 60℃,≤85% RH
Storage Environment	-30℃ ~ 70℃,≤85% RH
Power Supply Voltage	2.8V ~ 3.3V
Outline Dimension	61.24(W)x107.37(H)x1.60(D) mm
Viewing Area	52.44(W)x87.00(H) mm
Support Systems	Windows/Android/Linux etc.
Warranty	1 year
