Product Description
Projected capacitive 7 usb touch screen: support operation with gloves, water , and thick tempered glass or PC on top of the cover glass, mainly used in medical, industrial, security, home appliances and other fields; Custom processing such as surface treatment --AG,AR,AF available, resolution and brightness optional, etc.
| Model Number | HX0701601 |
| Brand | Grahowlet |
| Size | 7.0 inch |
| Interface Type | IIC/USB |
| Structure | G+G |
| Controller IC | Cypress |
| Touch Points | 10 points |
| Transparency | ≥85% |
| Surface Hardness | ≥6H |
| Operating Environment | -20℃ ～ 70℃,≤85% RH |
| Storage Environment | -30℃ ～ 80℃,≤85% RH |
| Power Supply Voltage | 2.8V ～ 3.3V |
| Outline Dimension | 165.00(W)x100.00(H)x1.45(D) mm |
| Viewing Area | 154.88(W)x86.72(H) mm |
| Support Systems | Windows/Android/Linux etc. |
| Warranty | 1 year |
FAQ
Q:Can you provide OEM service?
A:yes, we can provide both OEM and ODM service,can customize products according to the drawings you supply.
Q: What is the cause of the locally yellow spot on the display screen when the capacitive screen module is in use? How to solve it?
A: The macula is caused by the local thickness change when the LCD is pressed by the external force of the structure and not yet restored. At this moment, the light passing through the lcd is also different from other area where they are not squeezed, with the long time lighting of the screen, the temperature of the area being squeezed is higher than other place, which then forms the yellow spot.
The solution to remove the macula is to find out the root cause of external force and try to get rid of it.
