Product Description
-Fitted with a native, Full HD, LED IPS panel, 15.6 inch capacitive touch screen delivers outstanding image quality, vibrant colors and excellent ALL viewing angles. 15.6 inch capacitive touch screen is a capacitive multi-touch screen that can handle 10 touch points simultaneously. This provides extremely accurate operation supporting many different gestures, including swiping, zooming and more.
-The 15.6 inch capacitive touch screen works well with various operating systems including Linux, WinXP, Win7, Win8, Win10, Android, Ubuntu, and IOS, etc.
-And we can offer customized solutions which are prepared according to customer requirements. Our 15.6 inch capacitive touch screen may be produced in a selected shape, color, size of cover glass, thickness, corner with logo and other additional elements as per specification provided by the client.
TPM | Model Number | HX1561705 V2.0 |
Brand | Grahowlet | |
Size | 15.6 inch | |
Operating Temperature | 0℃ ~ 50℃ | |
Storage Temperature | -10℃ ~ 60℃ | |
Outline Dimension | 389.00(W)x237.05(H)x5.95(D) mm | |
Viewing Area | 345.43(W)x194.74(H) mm | |
Active Area | 344.16(W)x193.59(H) mm | |
Support Systems | Windows/Android/Linux etc. | |
Warranty | 1 year | |
CTP | Interface Type | IIC/USB |
Material/Structure | G+G | |
Controller IC | ILITEK | |
Touch Points | 10 points | |
Transparency | ≥85% | |
Surface Hardness | ≥6H | |
Power Supply Voltage | 5V | |
TFT | Resolution | 1920x1080 |
Interface Type | EDP | |
Luminance | 220 cd/m² | |
Viewing Angle | ALL |
Functional Characteristics
Capacitive touch screen has been increasingly used in various fields with rapid technology development. In order to meet different requirements of worldwide customers, GraHowlet supply all kinds of product structures such as G + G, G + F (G + F + F ),P + G, etc. and various technical support programs such as Cypress , Atmel, EETI, FocalTech, Goodix etc. according to different application environments.
Function Feature:
1) Glove function: support gloves made of various materials such as nylon, latex, cotton, plush and leather and of different thickness, 6mm the thickest.
2) Water function: support touch with water, oil, oil-water mixture and brine.
3) Thickness function: Support normal touch with thick cover like tempered glass, 8mm the thickest.
Application
FAQ
1.Can you send me the samples as soon as possible ?
Yes,we can ,if you check the information with us earily and finish the payment ,we will send the sampls to you when we receive the pay.
2.May I do the test by myslef ?
Yes ,when you got the samples you can do the test by yourself .if you have any questions just contact with us.
3.Would you like to help me visit your factory ?
Of course ,that will be our presure that you can come and see our factory.
4.How do i get sample?
Due to most of our products are high valued products, free sample is not available in Top-willing. if you need to order sample for checking up, we'd like to ask you to pay for the sample and shipping fee, and samples will be sent to you after receipt of payment.
5.What is the minimum order?
our company mainly deals with wholesale deals,but if you insist buying one set,welcome to take a sample for you check quality and function.
once sample is confirmed, we could allow for a small mount of orders(no quantity limitation) to be put into production and once this is confirmed, MOQ is required.
