Product Description
-Our 12.1 inch lvds touch display is compatible with 1024*768 resolution display screen, connected to your device through USB and hdmi interface, you can directly use after purchase.
-The 12.1 inch lvds touch display uses industrial touch chip ILITEK IC, can work with a variety of complex application environment. Such as work well with 3-10mm thickness cover glass, gloves and PC material onside.
-Apart from 12.1 inch lvds touch display, we also offers a range of ready-made PCAP touch screen solutions including our most popular 4.3", 5", 7", 8", 10.1", 10.4", 13.3", 15", 15.6", 17", 17.3", 19", 21.5", 23.6", 30" and 32" touch screens listed below.
-For more information, please contact us. Email/Skype: sales@grahowlet.com
>
| TPM Specifications | ||
| TPM | Model Number | HX1211702 |
| Brand | Grahowlet | |
| Size | 12.1 inch | |
| Operating Temperature | -20℃ ～ 70℃ | |
| Storage Temperature | -30℃ ～ 80℃ | |
| Outline Dimension | 265.76(W)x197.00(H)x12.10(D) mm | |
| Viewing Area | 246.76(W)x185.32(H) mm | |
| Active Area | 245.76(W)x184.32(H) mm | |
| Support Systems | Windows/Android/Linux etc. | |
| Warranty | 1 year | |
| CTP | Interface Type | I2C/USB |
| Material/Structure | G+G | |
| Controller IC | ILI2302M | |
| Touch Points | 10 points | |
| Transparency | ≥85% | |
| Surface Hardness | ≥6H | |
| Power Supply Voltage | 5V | |
| TFT | Resolution | 1024x768 |
| Interface Type | LVDS/HDMI/VGA | |
| Luminance | 350 cd/㎡ | |
| Viewing Angle | 80/80/80/80 | |
Product Catalogue
The catalog of our standard PCAP touchscreen :
| Size | Part No. | Structure | View Area(mm) | Lens OD(mm) | Interface | Touch IC |
| 1.3 | HX0131801 | P+G | 36.00*6.00 | 44.50*11.90*0.70 | I2C/USB | FT6336U |
| 2.4 | HX0241701 | G+F+F | 37.72*49.96 | 48.00*86.00*1.50 | I2C/USB | CYTMA568 |
| 3.2 | HX0321801 | G+F | 78.78*21.18 | 90.00*28.00*1.50 | I2C/USB | FT6336U |
| 4 | HX0401602 | G+F | 52.44*87.00 | 65.70*109.10*1.85 | I2C/USB | FT6336U |
| 4.3 | HX0431601 | G+G | 96.04*54.86 | 105.50*67.02*1.83 | I2C/USB | CYTMA568 |
| 5 | HX0501601 | G+G | 108.80*65.60 | 120.70*76.30*2.20 | I2C/USB | CYTMA568 |
| 5 | HX0501603 | G+F+F | 62.70*111.10 | 73.92*142.88*1.55 | I2C/USB | GT5688 |
| 5 | HX0501708 | G+F+F | 62.70*111.10 | 70.00*132.50*1.48 | I2C/USB | CYTMA568 |
| 5.5 | HX0551601 | G+F+F | 68.64*121.56 | 75.12*146.19*1.525 | I2C/USB | GT5688 |
| 5.6 | HX0561806 | G+F+F | 113.70*85.47 | 142.90*114.67*2.50 | I2C/USB | CYTMA568 |
| 7 | HX0701601 | G+G | 154.88*86.72 | 165.00*100.00*1.45 | I2C/USB | CYTMA568 |
| 7 | HX0701711 | G+G | 95.20*151.52 | 104.50*162.00*1.13 | I2C/USB | FT5316 |
| 7 | HX0701804 | G+G | 155.01*86.72 | 198.49*116.31*2.20 | I2C/USB | CYTMA568 |
| 8 | HX0801703 | G+G | 108.64*173.22 | 130.60*203.20*1.45 | I2C/USB | GT911 |
| 8 | HX0801804 | G+G | 163.00*122.50 | 193.00*151.00*3.90 | I2C/USB | CYTMA568 |
| 8 | HX0801806 | G+G | 163.00*122.50 | 183.00*141.00*2.00 | I2C/USB | CYTMA568 |
| 10.1 | HX1011701 | G+G | 217.76*136.40 | 247.96*166.60*2.00 | I2C/USB | CYTMA568 |
| 10.1 | HX1011703 | G+G | 217.56*136.20 | 241.60*163.20*1.80 | USB | ILI2511 |
| 10.4 | HX1041803 | G+G | 212.00*159.20 | 224.20*175.10*2.40 | I2C/USB | CYTMA568 |
| 12.1 | HX1211701 | G+G | 185.32*246.76 | 197.00*265.76*2.40 | USB | ILI2510 |
| 12.1 | HX1211801 | G+G | 247.50*186.00 | 326.80*236.80*2.40 | USB | ILI2510 |
| 13.3 | HX1331703 | G+G | 295.00*166.60 | 335.00*197.00*2.40 | USB | EETI3146 |
| 13.3 | HX1331801 | G+G | 294.76*166.24 | 333.76*210.24*2.00 | I2C/USB | CYTMA568 |
| 15 | HX1501703 | G+G | 305.00*228.00 | 328.00*255.00*3.30 | USB | ILI2302 |
| 15 | HX1501802 | G+G | 306.40*230.40 | 365.00*294.50*3.30 | USB | ILI2302 |
| 15.6 | HX1561704 | G+G | 345.43*194.74 | 389.00*237.05*2.00 | USB | ILI2302 |
| 15.6 | HX1561803 | G+G | 345.16*194.00 | 389.00*237.00*1.60 | USB | ILI2510 |
| 17 | HX1701701 | G+G | 338.92*271.30 | 377.00*309.00*2.40 | USB | ILI2302 |
| 17.3 | HX1731703 | G+G | 383.89*216.81 | 403.00*240.00*2.45 | USB | ILI2302 |
| 19 | HX1901701 | G+G | 376.32*301.06 | 421.60*346.60*3.30 | USB | ILI2302 |
| 21.5 | HX2151703 | G+G | 477.64*269.11 | 510.84*309.85*2.70 | USB | ILI2510 |
| 23.6 | HX2361801 | G+G | 522.28*294.22 | 588.80*363.10*3.65 | USB | ILI2510 |
| 30 | HX3001701 | G+G | 643.28*402.80 | 675.30*434.80*3.10 | USB | ILI2312 |
| 32 | HX3201803 | G+G | 698.70*393.30 | 754.70*449.30*5.05 | USB | ILI2312 |
| 43 | HX4301601 | G+G | 942.50*530.50 | 1013.20*600.50*5.30 | USB | ILI2315 |
| 55 | HX5501801 | G+G | 1212.60*683.40 | 1259.80*748.73*5.25 | USB | ILI2325 |
Custom Service
■ Programme evaluation : 1 to 2 working days
■ Drawings:2 to 3 working days
■ Customized products:3 to 4 weeks(after drawings confirmed)
■ Pruduction delivery :3 to 5 weeks
■ Capacity: 100K per month(10.1 inches as a reference)
■ Process capability: G+G, G+F+F, shielding process, overall module joint process(Optical Bonding)(maximum 65 )Cover glass surface treatment AR, AG, AF
■ Technical support :We have more than 10 years of experience in touch screen industry, with a professional technical team, can always provide technical support for you.
■ Stable supply chain for at least 3~5 years guarantee
■ One year warranty time for all of our product
■ Quality Assurance:Quality Control: Full-inspection of Function and Appearance by OQC
Efficient Customer Service : respond to quality complaint and returns in one day
Reliability Test: high and low temperature storage test, cold and hot shock test, ESD servo motor disturbance test, etc.
FAQFAQ
Q1: How is the quality of the product?
Our products have been strictly tested high quality by QC before shipping to customers.
Q2: What's your after-sale service?
If any problems, you will get our reply within 24 hours. Solution will be offered instantly.
Q3:What is the lead time of the products?
3-5 working days for Samples in stock after receiving payment. 4-6 weeks for bulk orders.
Q4: How long can I get reply?
Within 24 hours. Chinese working time 8:30-18:00 Monday-Friday online service to help you solve problems.Also reply by phone or email,Skype is possible at night time and weekends.
Q5: When the capacitive screen module is lightening, white spots, bright spots, dirty spots can be seen in the backlight, what is the reason? How to avoid it?
White spots and highlights are generally caused by impurities entering or damage to the backlight material. If there is impurity entering, what should be done is to trace the impurities from the LCM itself and find out where it comes from, and focus on the clean room assembly environment; if the backlight is damaged, it should be considered from the LCM structure, especially the product structure to find out what area of the structure poses a risk of injury or scratching to the LCM, and then eliminates it.
